Find the model that best meets
your needs.
PLANET Manufacturing Range
The PLANET® Family Angle rolls provide you with more working advantages, whether you need more accuracy, more power, greater flexibility, higher bending force or more rolling torque.
Three driven rolls
4-directional guide rolls:
axial adjust: manual
angular tilting: manual
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 26 cm³
Max. angle capacity: 80 x 9 mm.
Max. I-beams easy-way: 140 mm.
Max. H-beams hard-way: 80 mm.
Max. pipes capacity: 89 x 5 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 26 cm³
Max. angle capacity: 80 x 9 mm.
Max. I-beams easy-way: 140 mm.
Max. H-beams hard-way: 80 mm.
Max. pipes capacity: 89 x 5 mm.
Drive transmission: Hydraulic
Max section modulus: 60 - 110 cm³
Max. angle capacity: 100 x 12 mm.
Max. I-beams easy-way: 200 mm.
Max. H-beams hard-way: 120 mm.
Max. pipes capacity: 127 x 6 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 180 - 320 cm³
Max. angle capacity: 150 x 16 mm.
Max. I-beams easy-way: 320 mm.
Max. H-beams hard-way: 180 mm.
Max. pipes capacity: 219 x 6 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 350 - 570 cm³
Max. angle capacity: 160 x 20 mm.
Max. I-beams easy-way: 380 mm.
Max. H-beams hard-way: 200 mm.
Max. pipes capacity: 244 x 7 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 900 - 1500 cm³
Max. angle capacity: 200 x 28 mm.
Max. I-beams easy-way: 550 mm.
Max. H-beams hard-way: 300 mm.
Max. pipes capacity: 355 x 8 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 1800 - 3000 cm³
Max. angle capacity: 200 x 28 mm.
Max. I-beams easy-way: 600 mm.
Max. H-beams hard-way: 400 mm.
Max. pipes capacity: 457 x 11 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 2700 - 6500 cm³
Max. angle capacity: 200 x 28 mm.
Max. I-beams easy-way: 1000 mm.
Max. H-beams hard-way: 600 mm.
Max. pipes capacity: 508 x 15 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 6000 - 11000 cm³
Max. angle capacity: 200 x 28 mm.
Max. I-beams easy-way: 1000 mm.
Max. H-beams hard-way: 800 mm.
Max. pipes capacity: 609 x 25 mm.
Three driven rolls
6-directional guide rolls:
with fully hydraulic adjustment
from operator control panel
Combined design: vertical / horizontal
Drive transmission: Hydraulic
Max section modulus: 9500 - 18000 cm³
Max. angle capacity: 200 x 28 mm.
Max. I-beams easy-way: 1000 mm.
Max. H-beams hard-way: 1000 mm.
Max. pipes capacity: 711 x 22 mm.
COMBINING EQUIPMENT, TECHNOLOGY AND TRADITION TO HELP BUILD YOUR SUCCESS.
